Kirjeldus
Class AB Amplifier.
2 kanaline võimendi.
Power output @ 1ohm – N/A
Power output @ 2ohm – 2 x 125W RMS
Power output @ 4ohm – 2 x 75W RMS
Power output (Bridged) @ 4ohm – 1 x 250W RMS
RCA output – YES
S/N – >90db
Frequency response – 15hz – 20Khz
High pass filter – 32hz – 2Khz
Low pass filter – 50hz – 250Hz
Treble boost – 0/6/12 dB @ 10Khz
Treble boost frequency – 10Khz
BassBoost – 0dB / 6dB / 12dB
BassBoost frequency – 45hz
Input adjustment – 0.2V – 6V
Operation voltage – 10V – 16V
Fuse Rating – 1 x 30A
* RMS Power @ 14.4V, THD 1%
